Light industrial design
Plug & play, no need to install drivers
Support firmware upgrade
•Fast reading on all 1D/2D barcode on paper and screen.
•0.3 million high performance imaging technology, fast reading speed 60fps/s.
•Light industrial design, unique appearance, fashionable shape.
•Compatible with Windows 7/8/10, iOS, Android, Linux system.
•Plug and play, no need to install drivers, support firmware upgrade.
•Suitable for retail stores, supermarkets, restaurant, pharmacy, assembly line.
Image Sensor: CMOS
Light Levels: White LED (Lighting) RED aiming light
CPU: 32bit ARM
IP Standard: IP 54
Image Sensor: 640x480 pixels
Scanning Speed: 60fps
Decoding Depth: 60~360mm (13mil PCS90%)
Minimum Resolution: 3mil
Motion Tolerance: 13cm / second,(Skew/Pitch) +/- 65°
Interface: USB-HID, USB-VCP, RS232
Scan Mode: Manual & Automatic
Size: L*W*H : 112.5*81.5*204(mm)
Input Voltage: DC 3.6V ~ 5.5V
Working Current: 142mA
Stand-by Current: 42mA
Temperature(Operating): -10°C ~ 50°C
Temperature(Storage): -20°C ~ 60°C
Indicate: LED Indicator and Buzzer
Cable Standard: 2 Meters
Humidity: 5% ~ 95%(non-condensing)
Light Source: 0 ~ 5000Lux(fluorescent light),0 ~ 100,000Lux(daylight)
Decoding Capability: 1D: Codabar, Code11, Code39, Code32, Interleaved 2 of 5, Industrial 2 of 5,Matrix 2 of 5, Code93,
Code128, GS1-128, UPC-A, UPC-E, EAN 8, EAN 13, GS1 DataBar, RSS14, GS1 DataBar Limited,
GS1 DataBar Expanded, etc.
2D: PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec Code
