Camera
Max Resolution: 2 MP
Sensor: 1/2.9" CMOS
Min. Illumination:
Colour: 0.005 lux ( F1.6, AGC ON)
0 Lux with light
Day/Night: IR-cut filter with auto switch (ICR)
Shutter: Auto/Manual, 1 ~ 1/100000s
Adjustment Angle: Pan: 0° ~ 360°, Tilt: 0° ~ 80°, Rotate: 0° ~ 360°
S/N: >52 dB
WDR: DWDR
Lens
Focal Length: 2.8 mm
Iris Type: Fixed
Iris: F1.6
Field of View (H): 101.1°
Field of View (V): 55.0°
Field of View (D): 111.0°
Lens Type: Fixed
DORI
DORI Distance (Lens): 2.8mm
DORI Distance (Detect): 45.0(147.6ft)
DORI Distance (Observe): 18.0(59.1ft)
DORI Distance (Recognize): 9.0(29.5ft)
DORI Distance (Identify): 4.5(14.8ft)
Illuminator
Supplemental Light: Dual light
Illumination Distance (IR): 30 m (98.4 ft)
Illumination Distance (Warm Light): 30 m (98.4 ft)
Wavelength: 850 nm
IR On/Off Control: Auto/Manual
Video
Video Compression: Ultra 265, H.265, H.264
H.264 Code Profile: Baseline profile, Main profile, High profile
Frame Rate:
Main Stream: 2MP (1920*1080),Max 30fps; 720P (1280*720),Max 30fps
Sub Stream: 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps
Video Bit Rate: 128 Kbps to 6144 Kbps
U-code: Support(Main stream)
OSD: Up to 4 OSDs
Privacy Mask: Up to 4 areas
ROI: Support
Video Stream: Dual Streams
White Balance: Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2
Digital Noise Reduction: 2D/3D DNR
Smart IR: Support
Flip: Normal, Flip Vertical, Flip Horizontal, 180°
Dewarping: N/A
HLC: Support
BLC: Support
Defog: Digital Defog
Events
Basic Detection: Human Body Detection, Motion Detection, Audio Detection
General Function: Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication
Audio
Audio Compression: G.711U, G.711A
Audio Bitrate: 64 Kbps
Two-way Audio: N/A
Suppression: Support
Sampling Rate: 8 kHz
Storage
Edge Storage: Micro SD, up to 512 GB
Network Storage: ANR
Network
Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, QoS, SSL/TLS, SNMP
Compatible Integration: ONVIF (Profile S, Profile G, Profile T),
API, SDK
User/Host: Up to 32 users. 3 user levels: administrator, common user and operator
Security: Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client: UNV-Link, UNV-Link Pro, EZStation
Web Browser: Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
Interface
Audio I/O: N/A
Alarm I/O: N/A
Serial Port: N/A
Built-in Mic: Support
Built-in Speaker: N/A
WIFI: N/A
Network: 1 × RJ45 10 M/100 M Base-TX Ethernet
Video Output: N/A
Certification
EMC:
CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130)
FCC (FCC 47 CFR part15 B)
Safety:
CE LVD (EN 62368-1)
UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
Environment: CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
Protection: IP67 (IEC 60529)
General
Power: DC 12V±25%, PoE (IEEE 802.3af)
Power Consumption: Max 4.5W
Power Interface: Ø5.5 mm coaxial power plug
Dimensions: Ø118 x 98mm (Ø4.6” x 3.9”) (Ø x H)
Weight: 0.29kg(0.64lb)
Material: Metal + Plastic
Storage Environment: -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing)
Working Environment: -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing)
Surge Protection: 4 KV
Reset Button: N/A
Web Client Language: 4 Languages: English, Russian, Spanish, Vietnamese
