ZKTeco
ZKTeco SenseFace M2F-LR Fingerprint Time Attendance & Access Control Terminal with Adapter (Battery Backup)
Tk
15500
Face Capacity 3,000
Fingerprint Capacity 3,000
ID Card Capacity 3,000
Log Capacity 1,50,000
Built in battery, 2600mAh
1 Year Warranty
Built in battery, 2600mAh
1 Year Warranty
Access Control
Features
• Visible Light Facial Authentication Technology (only for SenseFace M2F-LR) and ZK Optical Fingerprint Authentication
• Multiple Authentication Methods:Facial (only for SenseFace M2F-LR) / Fingerprint/ RFID/ Password
• Available RFID Modules:125 kHz ID Card / 13.56 MHz IC Card
• Backup rechargeable battery (optional): offers at least 4 hours of power on a full charge, and it takes 5 hours to
recharge
• Support Online Firmware Upgrade
Model: SenseFace M2F-LR
Display: 2.8"@ TFT Color LCD Screen (320*240)
Camera: Binocular Camera @ 1MP
Operation System: Linux
Hardware:
◦ CPU: Dual Core@1GHz
◦ RAM: 512MB; ROM: 8GB
◦ Speaker: 8ohm @1W
◦ Supplement Light: Yes
◦ Physical Keypad: 16 Keys
◦ Fingerprint Sensor: ZK Optical Sensor
◦ Casing Color: Black and White
Authentication method: Fingerprint / Face / Card / Password (Physical Keypad)
Fingerprint Template Capacity: 3,000
Face Template Capacity: 3,000
ID Card Capacity: 3,000
Log Capacity: 1,50,000
Max. User Password Length: 8 Digits
Biometric Authentication Speed:
◦ less than 1 sec (Fingerprint)
◦ less than 1.2 sec (Facial Authentication)
Touchless Biometric Recognition Distance: 50cm to 180cm (Facial Authentication)
False Acceptance Rate (FAR) %:
◦ FAR ≤0.02% (Visible Light Facial Authentication)
◦ FAR ≤ 0.0001% ( Fingerprint )
False Rejection Rate (FRR) %:
◦ FRR ≤ 0.05% (Visible Light Facial Authentication)
◦ FRR ≤ 0.1% (Fingerprint )
Biometric Algorithm:
◦ ZKFace V4.0
◦ ZKFingerprint V13.0 (Standard) /V10.0 (Optional)
Card Type:
◦ ID Card@125 kHz (Standard)
◦ IC [email protected] MHz (Optional)
Communication
◦ TCP/IP*1
◦ Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional)
◦ USB: Type A (USB Drive Only )*1
◦ Electric Lock*1, Door Sensor*1, Exit Button*1
Standard Functions
◦ ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Record Query, Schedule Bell, Tamper Switch Alarm,
◦ Automatic Status Switch, Multiple Authentication Methods, HTTPs / SSH Backend Access, T9 Keyboard (Input)
Optional Functions: IC Card, Wi-Fi, Backup Battery
Power Supply: DC 12V 1.5A
Backup Battery (Optional):
◦ 2,000 mAh (Lithium Battery)
◦ Max. Operating Hours : 4 Hours
◦ Max. Standby Hours: 7 Hours
◦ Estimated Charging Time: 5 Hours
Operating Temperature: -5°C to 45°C
Operating Humidity: 10% to 90% RH (Non-condensing)
Dimensions: 154 mm*138 mm*34 mm (L*W*H)
Gross Weight: 1.03 kg
Net Weight: 0.43 kg
Supported Software:
◦ Mobile App.: ZKBio Zlink
◦ Cloud-based Software: ZKBio Zlink
◦ On-Premise Software: ZKBio Time
Installation: Wall-mount (Compatible with Asian Gang Box / Single Gang Box)
Certifications: ISO14001, ISO9001,CE, FCC, RoHS
