Microphone: *1 (Sensitivity: -32dB / Omni-directional / Signal-to-Noise Ratio: -32dB / Impedance: 2.2kΩ)
IC Card @ 13.56 MHz (Optional)
Communication
TCP/IP*1, Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional), Wiegand (Input or Output)*1
RS485: ZKTeco RS485*1, USB: Type A (USB Drive Only)*1
Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, 12V Output*1
Standard Functions:
ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple Authentication Methods, SIP Client (Version 2.0), ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC Push and TA Push Protocol Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input)
Optional Functions:
IC Card, Wi-Fi, Wireless Doorbell
Video Intercom:
Video Intercom (ZKTeco Private Protocol via TCP/lP)
Support Devices:
Standalone Terminal: SenseFace Series
Indoor Monitor: VT07-B01, VT07-B01-W
Video Intercom (Standard SIP Protocol)
Support Devices:
Standalone Terminal: SenseFace series
Indoor Monitor: VT07-B22L, VT07-B26L-W
Software: ZKBio CVSecurity, BioTalk Pro
Mobile App: ZKBio Zlink, ZKBio Zexus
Access Control Interface: RS485 (RS485 Card Reader / Biometric Reader)
Power Supply: DC 12V 3A (Optional)
Operating Temperature: -5°C to 45°C
Operating Humidity: 10% to 90% RH (Non-condensing)
Dimensions: 214mm * 115mm * 22.3mm (L*W*H)
Net Weight: 0.622 Kg
Supported Software:
On-Premise Software: ZKBio CVSecurity (AC PUSH) & ZKBio Time (TA PUSH)
Cloud-based Software: ZKBio Zlink (Supports Web Portal & Mobile App)
Installation: Wall-mount (Compatible with Asian Gang-box / Single Gang-Box)
Ingress Protection Rating: IP65 (waterproof and dustproof )
Certifications: ISO14001, ISO9001, CE, FCC, RoHS
