• Incoming BW : 384Mbps
• Stability: Linux OS, dual-BIOS, redundant power, two-server hot standby
• Compatibility: Third-party IP Cameras supported with standard ONVIF and RTSP
• Access: Browser/Server, Client/Server and mobile clients (both iOS and Android)
• Connection: 1000 device connections, up to 2000 channels of high-definition network videos
• Management: Unified management of IPC, NVR, face recognition terminal, decoder, network keyboard,
cloud devices, alarm control panel and door access control, support devices’ configuration import/export
• Storage: Max 16 hard disks and 2 disk enclosures; expandable up to 48 disks with 672TB storage, recording backup, IPSAN storage
• Decoding: Max 16×1080P decoding outputs in three screens, expandable up to 112×1080P in 15 screens with 2 decoding cards inserted
• Service: Live view, playback, sequence, video wall, GIS map, two-way audio, and alarm plan
Video management
Number of connected cameras per server:
1000 devices or 2000 channels
1000 devices connected via Onvif
Number of connected face recognition terminals: 128
Image processing performance:
Receive vehicle or face images: 100 images per second
Note: For example, if each device uploads 1 image per second, then 100 devices can be connected; if each device uploads 5 images per second, then 20 devices can be connected
Device management: IPC, NVR, face recognition terminal, decoder(standard/expanded), network keyboard, cloud devices, alarm control panel and door access control
Number of 3rd-party alarm control panels/access control devices: 30
Numbers of users: 1000
Numbers of online users: 300
Numbers of roles per user: 16
Bandwidth of video input per server: 512Mbps
Bandwidth of video output per server: 384Mbps
Decoding
Video compression: Ultra265, H.265, H.264
Decoding: 4×4K@30, 16×1080p@30, 36×720p@30, 64×D1
Resolution: 12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/960H/D1/2CIF/CIF/QCIF
Display on video wall: HDMI(×2) and VGA(×1) output; HDMI output supports 4K resolution
Audio compression: G.711A, G.711μ
Decoding card (optional): Max 2 cards supported; models: HDMI4-C and HDMI6-C
HDMI4-C decoding card: 4-ch HDMI outputs, with decoding of 4*4K@60 or 8*4K@30 or 32*1080P@30 or 64*720P@30
HDMI6-C decoding card: 6-ch HDMI outputs, with decoding of 6*4K@60 or 12*4K@30 or 48*1080P@30 or 96*720P@30
Storage
HDD installation:
Hot-swappable HDDs
Support 16HDDs (3.5", up to 14TB for each )
RAID mode: RAID0, RAID1, RAID5,RAID6,RAID10,RAID50,RAID60,JBOD
Performance of video storage per server: 512Mbps/ 256 channels * 1080P
Disk enclosure (optional): Max 2 disk enclosures supported; models: DEU1008 and DEU1016
DEU1008 disk enclosure: 8xSATA interfaces, up to 14TB storage per interface
DEU1016 disk enclosure: 16xSATA interfaces, up to 14TB storage per interface
Play control:
1 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 13 / 16 / 17 / 25 / 32 / 36 / 64 window display
Corridor format
Up to 3 auxiliary monitors
Playback:
Play NVR recordings
Up to 24 channels for multiple clients; synchronous playback up to 16 channels for single client
Data Info
Alarm Records: 200,000
Operation logs: 200,000
Face capture records: 3 million
Face alarm records: 3 million
Vehicle pass-through records: 3 million
Structured motor vehicle, non-motor vehicle and pedestrian records: 3 million
Access control entry/exit records: 3 million
Alarm processing capacity: 100/s
System
Main Processor: Intel(R) CPU
Memory: 4GB DDR3L
Power supply:
100-240 VAC (with power on/off switch)
Dual-power redundancy (Hot Swap support)
Interface
Network:
4×10M/100M/1000M Base-T adaptive Ethernet interfaces
2×1000M SFP optical interfaces
USB: 4×USB3.0
HDMI: 2×HDMI
VGA: 1×VGA
Serial: 1×RS-232 (RJ45), 1×RS-485 (RJ45)
Alarm input/output: 24×alarm inputs, 8×alarm outputs
Power output: 12 V DC
Audio alarm: Buzzer
Expansion:
1×eSATA interface
2×miniSAS interfaces
2×decoding cards
Others
Power consumption:
≤ 50W (not including HDD)
≤ 165W (including HDD)
Operating temperature: -10°C to 55°C (14°F to 131°F)
Operating humidity: 10% to 90% (noncondensing)
Weight: ≤ 10.0 Kg
Dimensions (D×W×H):
Height: 3U, support mounting in standard 19" cabinet
477.1 mm × 481.6 mm × 130.5 mm (18.8''×19''×5.1'') (including front panel)
