Uniview

Uniview PKG5301W-LR-ZG-40-A + PKG-ZG-40-A + PKR5301-A + PKP-MK-TG1-A Boom Barrier

Ask For Price

Model: PKG5301W-LR-ZG-40-A
Model: PKG-ZG-40-A
Model: PKR5301-A
Model: PKP-MK-TG1-A

Price - 8,17000 tk

Model: PKG5301W-LR-ZG-40-A

Motor Type: Brushless DC hybrid motor

Transmission Structure: Gear transmission

Lifting Time: Adjustable from 2 to 6 seconds; see speed matching table for details, subject to boom length.

Lifting Cycles: 23.5 million cycles

Remote Control Distance: Supports ≤30m$

Remote Controller Functions: Open, Close, Pause

Barrier Control: Default dry contact signal transmission, supports RS485 signal transmission

Anti-Crush Radar: Built-in radar mounting holes, compatible with anti-crush radar

Loop Anti-Crush: Supported

Model: PKG-ZG-40-A

Installation Method: Clamp Plate Mounting

Type: Straight Boom

Boom Arm Length: 4m

Material: 1.1 mm Aluminum Alloy

Arm Color: White Boom with Red Reflective Film

Weight: 4.6KG

Model: PKR5301-A

Detection Target: Supports person/vehicle discrimination; disabled by default

Beam Width: Horizontal ±40°, Vertical ±9°

Detection Range: Default ±1 m (±1.5 m configurable for straight booms; fence and advertising

booms limited to 1 m, not adjustable)

Response Time: 100ms

Interface: 1-Channel Dry Contact Output

Model: PKP-MK-TG1-A

Input Voltage: 24V

Output Voltage: 21V

Output Current: 15A

Operating Temperature: -30~70°C

Operating Humidity: 20% to 90% Relative Humidity, no condensation

Weight: 0.43KG
