4K UHD anti-glare display delivers images with extreme
detail Resolution 3840 x 2160
Backlight DLED
Brightness (cd/m²): 350
Contrast ratio: 1200:1
Key Features
• 4K UHD anti-glare display delivers images with extreme detail.
• Zero bonding technology between lcd panel and cover glass brings brighter viewing and smoother touching experience.
• Ultra-narrow and equal-width bezel design for perfect aesthetics.
• Minimalist geometric line design and smooth border outline, elegant and attractive.
• 8MP professional HD camera for more immersive remote collaboration.
• Omni-directional 8-array microphone, 8m pickup distance, zero communication distance.
• Dual Wi-Fi modules with both Wi-Fi and hotspot support.
• vDual-channel, 6-array speaker brings high-quality surround sound.
• High-precision infrared touch technology allows up to 20-point touch, realizing smooth co-authoring.
• Bluetooth 5.2 offers higher data transmission rate, and lower power consumption.
• 4K UI, mobile-level operation, just like use a mobile phone.
• A variety of quick tools, such as annotation, screenshot, etc., improve usability and interaction efficiency.
• Wireless screen mirroring from various operating systems such as Android, iOS and Windows to the display with one touch.
• Fast file transfer. Allows users to quickly transfer files to the display via a QR code.
• OTA remote upgrade. The system can be upgraded online without backing up data.
Panel
Backlight: DLED
Panel size: 65 inches
Resolution: 3840*2160
Brightness (cd/m²): 350
Contrast ratio: 1200:1
Response time (ms): 8
Color support: 1.07B
Viewing angle (H/V) :178°/178°
Android
CPU: RK3588: 4-core A76 (2.4G) + 4-core A55 (1.8G)
CPU frequency: 2.4GHz
RAM/ROM: DDR4: 8GB eMMC: 64GB
Android version: Android 12.0
Touch
Touch control: Infrared touch screen, 20-point multi-touch at most
Touch precision (mm): ±1
Recognizable object: 5 points 2mm
Glass: 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare
Response time (ms): ≤10
Touchscreen input: Opaque objects (e.g. finger, pen, etc.)
Interface
Video input: 3*HDMI IN (4K@60)
Video output: 1*HDMI OUT (4K@60)
Audio input: 1*AUDIO IN
Audio output: 1*AUDIO OUT
Control: 1*RS232、3* USB 3.0、1* USB Type C、1* USB Type B
Network: 2*RJ 45,10M/100M/1000M adaptive Ethernet Interfaces
Audio
Frequency domain: 80Hz~20kHz
Speaker:
Left channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W)
Right channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W)
Wi-Fi
Configuration: Wi-Fi6 + Wi-Fi5 dual-module, supports 5G/2.4G
Performance: 30 m² coverage, 20m transmission distance in open space
Bluetooth
Version: 5.2
Performance: 10m transmission distance in open space
OSD
Language supported: 3 (Simplified Chinese、English、Spanish)
VESA
Wall mount hole (mm): 500*400
Wall mount screw: 4-M8 screw hole
General
Power supply: AC 100 to 240V, 50/60Hz
Maximum power consumption (W): ≤220 (on without OPS)
Standby power consumption (W): <0.5
Operating temperature: 0 to 50°C
Operating humidity: 10% to 90% (non-condensing)
Storage temperature: -20 to 60°C
Storage humidity: 0% to 95% (non-condensing)
Product dimensions (W*H*D)(mm): 1498*911*89
Package dimensions (W*H*D)(mm): 1632*1081*222
Weight (kg)
Net weight: 40.5
Gross weight: 49.0
