Printing way: Thermal sensitive line dot method
Printing way: Thermal sensitive line dot method
Paper width: 56mm
Valid printing width: 48 mm
Paper thickness: 60 ~ 80μm
Rolling paper Diameter: ¢40(max)X58mm
Paper feeding method: Easy paper loading
Resolution: 8 dot/mm (203 dpi)
Dot /line: 384 dots/line
Printing speed: 80 mm/s (max)
Print Font: ASCII Font A: 12×24/ASCII Font B: 9×24/Chinese: 24×24
Characters per Line: Font A: 32/Font B: 42/Chinese: 16
MCBF: 5 Million Lines
Print head lifespan: 50 km
Interface: Bluetooth(BT4.0&BLE)/WiFi/USB/RS232
Barcode type:
CODE39/EAN-13/EAN-8/CODABAR/
CODE93/ITF/QR/PDF417
Paper sensor: Support
Printing Command: ESC/POS
Battery:
1. 1600 mAh rechargeable li-ion battery
2. Continuously working for 5.5 hours or 195m
3. 3-5 hours charging time
4. lifespan is more than 500 times.
Power alarm: Exclusive power indication light turn off and red light flashes when the printer is running out of power. Then it must be charged or changed the battery.
Power Supply: USB/Power adapter/mobile power charging
Environment parameters:
Working temperature: -10℃~ 50℃
Working humidity: 20% ~ 85%
Storing temperature : -20℃ ~ 70℃
Storing humidity: 5% ~ 95%
Outer dimension(LxWxH): 112*79*45mm
Weight: 335g (including the paper roll and battery)
