Rongta
RONGTA RP215-U WRISTBAND BARCODE LABEL PRINTER W/USB INTERFACE
Tk
21500
Printing method: Thermal
Resolution: 203dpi
Maximum print width: 2.2''(56mm)
Maximum printing speed: 6 ips(150mm/s)
Thermal Printer
• Exquisite appearance, simple and elegant;
• Widely used in drinking label, shopping receipt, parking receipt, medical wristband and and other scenarios printing;
• Small size, save space;
• With high speed, significantly reducing wait times;
• Support print a wide range of labels in different sizes/materials, perfect for multiple scenarios;
• Support multiple barcode printing and languages;
• Support wristband printing, medical bottle labeling printing prescription printing, case labeling, continuous paper printing.
Print
Printing method: Thermal
Resolution: 203dpi
Maximum print width: 2.2''(56mm)
Maximum printing speed: 6 ips(150mm/s)
Print length: 0.79''-15.75''(20-400mm)
Sensor: Seam mark detection, black mark detection, paper shortage detection, backflow detection, cover opening detection, head temperature detection
Medium
type: Bottom black mark, continuous paper, folding paper, wristband label
Width (label + backing paper): 2.56''(65mm)(MAX)
Thickness (label + backing paper): 0.0023''-0.0071''(0.06mm~0.18mm)
Maximum paper roll diameter: φ3.94''(φ100mm)
Reel inner diameter: φ1''(φ25mm(MIN))
Paper tearing method: Manual tearing
processor: 32-bit ARM MCU
storage
RAM: 8MB
FLASH: 8MB
Function
button: Power switch, pause button, FEED button, paper bin cover opening button
Indicator Lights: YES
buzzer: Buzzer tone
Display: /
other: First sheet returned, reprinting due to lack of paper
Communication interface: USB
programming language: TSPL+ZPL+ESC
Built-in fonts:
ASCll Font: 10x12, 14x20, 16x24, 24x32, 36x48, 14x19, 21x27, 14x25, 12x24
GB18030: 16x16, 24x24
Code Page
Extended character table: CP437, CP850, CP852, CP860, CP863, CP865, CP866, WPC1250, WPC1251, WPC1252, WPC1253, WPC1254
Barcode
1D: Code39, Code39C, I25, Code93, ITF25, EAN128, Code128, Codabar, EAN-8, EAN8+2, EAN8+5, EAN -13, EAN13+2, EAN13+5, UPC-A, UPCA+2, UPCA+5, UPC-E, UPCE+2, UPCE+5MSIC, ITF14, EAN14, Code11
2D: QRCODE, PD417, DateMatrix
software
drive: XP, Win7, Win8, Win10, Win11, ios, Android
SDK: Android, iOS, Windows
Label design: Barcode label editing software (PC), APP
Power adapter
Input: AC 100-240V, 50/60Hz
Output: DC 24V/2.5A
Environmental parameters
Work: Temperature: 32-104℉(0-40℃); Humidity: 20-90% (non-condensing)
storage: Temperature: 14-140℉(-10-60℃); Humidity: 5-95% (non-condensing)
Physical parameters
Dimensions (length, width, height): 104mm*210mm*143mm
weight: 1.5kg
Accessories
Standard: Power cord, USB data cable, power adapter, quick installation guide, certificate of conformity
Optional: Battery
standard: CCC, CE, FCC
